The Only Food-Grade SEALTITE® Fittings on the Market!

METALLIC FITTINGS

SEALTITE® FOOD GRADE FITTINGS   STAINLESS STEEL AISI-316 PREMIUM NPT FITTINGS

DESCRIPTION

Stainless steel AISI-316 fitting, consisting of 6 parts (counter nut, upper seal, clamping ring, ferrule, body, and 304SS locknut).

• Special approvals: Special TPE seals, halogen free, specially formulated for food and beverage applications per FDA guideline CFR 21.

• Hygienically designed with rounded corners and a smooth contourless profile to minimize the risk of bacteria deposits and to promote easy cleaning

• Evaluated and in compliance with the current criteria for Hygienic Equipment Design of the EHEDG (report .DTU CHD DR 2017 8037-088-3) locations

SPECIFICATIONS

• AISI-316 body with AISI-304 Ferrule and lock nut and TPE clamping ring

• Color: Metallic

• Temp. range: -40o F to +221o F (-40o C to + 105o C)

• cULus Approved # E234207

• IP 68 rated according EN 60529, IP 69 rated according DIN 40050-9 (till 40 Bar high pressure)

• NSF/ANSI 169


APPLICATIONS

• Rated for Food Zone non-contact and Splash Zone applications

• Metallic and Type B non-metallic flexible conduit

• Premium Stainless 316 for the best corrosion resistance

• Compact design for tight spaces

COMMON NEC Articles

• 501.10 (B) (2) Class I Div. 2

• 502.10 (A) (2) and (B) (2) Class II Div 1 & 2

• 503.10 (A) (3) and (B) Class III Div. 1 & 2






culus
thumb_rohs compliant
